Wemax Power
1 / 5
| Series No. | WMX-D60D12 |
| Model | WMX-DSD60S1220 |
| Product Name | dc converter 60v 12v |
| Input rated voltage | 60Vdc |
| Input voltage range | 30-90Vdc |
| Conversion Efficiency | 96% |
| Output voltage | 12Vdc |
| Output current | 20Amps |
| Output rated power | 240Watts |
| Voltage regulation | < 1% |
| Load regulation | < 2% |
| Ripple (full load test) | < 150mV |
| No-load current | < 20mA |
| Working Temperature | -40°c ~ +80°c |
| Waterproof rating | IP 67 |
| Protections | Over-load, Over-current, Over-temperature, Over-voltage |
| Machine size | 100*80*39mm |
| N. Weight | 490g |
| Cooling way | Free air convection |
| Packing | White standard box |
