| Model | WMX-B2B12S5830 |
| Product Name | 12V to 58V 30A DC TO DC Battery Charger |
| Input rated voltage | 12V DC |
| Input voltage range | 12.5-16V DC |
| Conversion Efficiency | 96% |
| Output voltage | 58V DC |
| Output current | 30 Amps |
| Output rated power | 1740Watts |
| Voltage regulation | < 1% |
| Load regulation | < 2% |
| Ripple (full load test) | < 150mV |
| No-load current | < 20mA |
| Working Temperature | -40°c ~ +80°c |
| Waterproof rating | IP 68 |
| Protections | Over-load, Over-current, Over-temperature, Over-voltage |
| Machine size | 220*156*65mm |
| N. Weight | 3.5kg |
| Cooling way | Free air convection |
| Application | 12V -58VDC 30A DC-DC Charger, mainly apply for Lead acid or Li-ION or LiFePO4 Lithium Battery on RVs, exposed cars, campers, ships, etc. |
We offer you the best quality products and service. Win-win business is our first principle.
The product series includes DC-DC Converters, AC-DC Converters, DC power supplies, Battery Chargers, etc. These products are widely used for home applications, motors, photovoltaic panels, cars, and more.
Yes, we are the direct manufacturer and we supply OEM/ODM services.
1. Guarantee time: one year.
2. Return policy: we can exchange goods if there is a quality problem.
1. Payment terms: L/C, T/T, Western Union, MoneyGram, Paypal, etc.
2. Shipping terms: Sea freight, DHL, UPS, FEDEX, TNT, EMS.
3. Sample orders are delivered within 24 hours, and standard order lead time is within 3 days.
We offer a low MOQ, and 10 units for sample testing is available.
