Suitable for GEL, Sealed, Flooded, LifePO4, Lithium-ion
Booster 30a MPPT solar 20a Charger Smart charger DC to DC Charger Support APP Automatic Smart For RVs Campers
| Parameter | Specification Details |
|---|---|
| Model | WMX-BS123020 |
| Main battery | 12Vdc |
| Main battery type | GEL, Sealed, Flooded, LifePO4, Lithium-ion |
| Vehicle starter battery | 12V |
| Starter battery type | Lead acid |
| DC-DC Max charging current | 30A |
| Solar Max charging current | 20A |
| Solar max voltage | 50V |
| Self-consumption current | 24Ma |
| Dimension | 190*194*70mm |
| Net Weight | 1.44KG |
| Accessories (Pay additional cost if needed) |
Monitor (MT-2) - Optional Blue tooth-Dongle (BT10) - Optional Temperature Sensor (TRS) - Optional |
| Battery Type | Equalized Charge | Boost Charge | Float Charge | HVD | LVD | Constant Voltage Charging Time |
|---|---|---|---|---|---|---|
| GEL | - | 14.3V | 13.8V | 15.5V | 11V | 2 hours |
| Sealed | 14.6V | 14.4V | 13.5V | 15.5V | 11V | 2 hours |
| Flooded | 14.6V | 14.7V | 13.5V | 15.5V | 11V | 2 hours |
| Life-PO4 | - | 14.6V | 14.5V | 15.5V | 11V | 2 hours |
| Li-ION | - | 12.6V | 12.5V | 13.5V | 9.3V | 2 hours |
RVs, exposed cars, campers, ships Battery to battery DC & Solar Panel 10-16v 12v Input to 14.6V Boost DC to DC Charger 30A Lithium battery with 2 charging sources. You can use the battery (12V) to charge the battery (12V) (B2B), or you can use the solar panel to charge the battery with automatic intelligent switching charging methods, specially designed for RVs, exposed cars, campers, ships, etc.
Mobile operation from dynamo and starter battery (Battery to Battery):
Refers to charging the main battery through dynamo and starter battery. If not used in a vehicle, you can also use one 12V battery to charge another.
