| Model Definition | WMX-ASD XXX YYY (XXX: Output Voltage; YYY: Output Current) |
|---|---|
| Input Voltage Options |
1 Phase: AC110/120V±10%, 50Hz/60Hz 1 Phase: AC220/230V±10%, 50Hz/60Hz 3 Phase: AC208/380V±10%, 50Hz/60Hz |
| Output Voltage | 0-800Vdc |
| Output Current | 2-20A adjustable or 0-20A Adjustable |
| Output Power | 16000W (16KW) |
| Load Regulation | ≤0.5% + 30mV |
| Ripple | ≤0.5% + 10mVrms |
| Power Supply Stability | ≤0.3% + 10mV |
| Display Accuracy | Precision of 4 digit table: ±1% + 1 word (10% - 100% rating) |
| Display Format | 0.000 ~ 9999V; 0.00 ~ 99.99V; 0.0 ~ 999.9A |
| Output Voltage Overshoot | Built-in O.V.P Protection with a rate of +5% |
| Over-Temperature Protection | (75 ~ 85) °C |
| Cooling Mode | Forced air cooling |
| Efficiency | ≥83 ~ 86% |
| Start-up Output Voltage Time | ≤3S |
| Protection Features | Under-voltage, over-voltage, over-current, short circuit, and over-temperature protection. (Optional: Reverse Connection & Polarity reversal protection can be factory customized) |
| MTTF | ≥50000h |
| Dimension | 695 * 520 * 470mm |
| Remote Control Function (Option) |
• 0-5Vdc / 0-10Vdc analog signal control output voltage & current • 0-5Vdc / 0-10Vdc analog signal read-back output voltage & current • 0-5Vdc / 0-10Vdc analog switch signal to control output ON/OFF • 4-20mA analog signal control output voltage & current • RS232/RS485 Communication port control via computer |
