| Model | WMX-ASD XXX YYY |
|---|---|
| WMX | WEMAXPOWER |
| ASD | AC Input Switch to DC Output |
| XXX | MAX Output Voltage |
| YYY | MAX Output Current |
| Brand | WEMAXPOWER |
| Model definition | WMX-ASD XXX YYY (XXX---Output Voltage ; YYY---Output Current) |
| Model (WMX-ASD) | WMX-ASD40010 |
| Input Voltage |
Option: 1 Phase: AC110V±10%, 50Hz/60Hz; 1 Phase: AC220V±10%, 50Hz/60Hz; 3 Phase: AC380V±10%, 50Hz/60Hz; |
| Output Voltage (Vdc) | 400VDC |
| Output Current (Amp) | 10A |
| Output Power | 4000W |
| Load Regulation | ≤0.5% +30mV |
| Ripple | ≤0.5% + 10mVrms |
| Power supply stability | ≤0.3% +10mV |
| Voltage | Current Display Accuracy | Precision of 4 digit table : ±1%+1 word (10%-100% rating) |
| Voltage | Current value display Format | Display format: 0.000 ~ 9999V; 0.00 ~ 99.99V; 0.0 ~ 999.9A; |
| Output Voltage Overshoot | Build in O.V.P Protection with a rate of + 5% |
| Operation Temperature | Humidity | Operation Temperature : (0~40)℃; Operation Humidity : 10% ~ 85% RH |
| Storage Temperature | Humidity | Storage Temperature : (-20~70)℃; Storage Humidity : 10% ~ 90% RH |
| Over-Temperature Protection | (75~85) C. |
| Heat Dissipation Mode / Cooling mode | Forced air cooling |
| Efficiency | ≥86% |
| Start-up Output voltage setting time | ≤3S |
| Protection |
Lower voltage, over voltage, over current, short circuit, overheating Protection Noted: if need addition Reverse Connection & Polarity reversal protection should be contact factory customized |
| Insulation Strength |
Input output: AC1500V, 10mA, 1 minutes; Input - machine shell: AC1500V, 10mA, 1 minutes; Output - shell: AC1500V, 10mA, 1 minutes |
| Insulation Resistance |
Input-Output ≥20MΩ; Input-Shell ≥20MΩ; Output-Shell ≥20MΩ. |
| MTTF | ≥50000h |
| Dimension / Net Weight | 445*225*185mm , NW 15.5kg |
| Analog Remote Control Function (Option) | |
| Remote Control Function (Option) |
• 0-5Vdc /0-10Vdc analog signal control output voltage & current • 0-5Vdc /0-10Vdc analog signal to read-back output voltage & current • 0-5Vdc /0-10Vdc analog Switch signal to control output ON/OFF • 4-20mA analog signal control output voltage & current • RS232/RS485 Communication port control by computer |
| Customized Service | |
| Output Voltage/Current |
1~20000V can customized, Stabilizer value. 0% to 100% adjustable 1~25000V can customized, Constant current value. 0% to 100% adjustable Option, Free combination of voltage and current according on user request |
1Why choose this variable DC power supply?
We offer you high-quality products and services designed to meet rigorous industrial applications, prioritizing mutual business success as our leading principle.
2What is the product range of your manufacturing capabilities?
The product line includes DC-DC Converters, AC-DC Converters, variable DC power supplies, and Battery Chargers. These products are widely utilized in home applications, motors, photovoltaic systems, automotive sectors, and more.
3Are OEM and ODM customization services available?
Yes, direct manufacturing allows us to supply comprehensive OEM and ODM services. Custom specifications for input/output voltage and current can be customized to requirements.
4What are the after-sales service and warranty terms?
We provide a 12-month guarantee period. For any verified quality concerns, exchange options are supported under the return policy.
5What are the standard payment terms and shipping logistics?
Available payment options include L/C, T/T, Western Union, MoneyGram, and PayPal. Shipments are handled via major carriers such as DHL, UPS, FedEx, TNT, and EMS. Sample orders are typically processed within 24 hours, with standard order lead times around 3 days.
6What is the Minimum Order Quantity (MOQ) for this adjustable DC power supply?
A low MOQ is supported, and a single set is available for initial sample testing.
