Product Description

17-38vac Input Range 36vac to 12vdc AC-DC Converters Monitor Module 2A
36v to 12v AC to DC Converter
17-38vac Input Range 36vac to 12vdc Ac-dc Converters Monitor Module 2A 36v to 12v Ac to Dc Converter
>>> 36vac to 12vdc ac to dc converter module <<<
Divider
  • High quality components.
  • Full power, stable voltage & current output.
  • Wide input voltage range 8-40vdc.
  • Waterproof IP67 & anti-shock protection, Ultra compact size, light weight.
  • Industry grade product, efficiency up to 96%.
  • Die-cast aluminum shell, epoxy potting.
  • Non-Isolated Module.
Divider
Series No. WMX-A36D12
Model WMX-ASD36S2402
Product Name 36vac to 12vdc ac dc converter
Input rated voltage 36Vac
Input voltage range 17-38Vac
Conversion Efficiency 94%
Output voltage 12Vdc
Output current 2Amps
Output rated power 24Watts
Voltage regulation < 1%
Load regulation < 2%
Ripple (full load test) < 150mV
No-load current < 20mA
Working Temperature -40°c ~ +80°c
Waterproof rating IP 67
Protections Over-load, Over-current, Over-temperature, Over-voltage
Machine size 58*40*22mm
N. Weight 90g
Cooling way Free air convection
Packing Static bag packaging
Divider
17-38vac Input Range
Product Diagram
Product Description
Product Details
Technical Specifications
Product Feature 1 Product Feature 2 Product Feature 3
Application Fields
FAQ
QWhy choose us?
We are a professional AC-DC converters manufacturer with more than 10 years of industry experience. The performance of our converters is highly stable, and our product technology is updated annually.
QWhy are other products cheaper than yours?
Many other suppliers use low-cost components which often result in insufficient power output. Our products are made with imported, high-grade components that support long-term, full-load operation safely.
QWhat about your after-sales service?
We provide a 1-year guarantee. Within the warranty period, we offer product exchanges for any verified quality issues.
QWhat are your payment and logistics terms?
We support payment methods including L/C, T/T, Western Union, MoneyGram, and PayPal. Shipping options include DHL, UPS, FedEx, TNT, EMS, and Sea Freight.
QWhat benefits do you offer?
We provide excellent products with unique design and strict quality control, outstanding support (including OEM/ODM, after-sales services, fast delivery), and professional business consultation.
QWhat is the MOQ for the 36vac to 12vdc ac-dc converter?
We support low MOQ requirements. A sample testing order of 10 units is available.
