| *Adjustable Power Supply Series* | ||||
| 500~1000W | 1501~2000W | 3001~4000W | 6001~8000W | 10.1~12KW |
| 1001~1500W | 2001~3000W | 4001~6000W | 8001~10KW | 12.1~20KW |
DC Power Supply is widely applied into industrial control, electronic power, electroplating, communication, scientific research, instrument, military, medical, ship, railway and other high-tech fields.
| Parameter | Specification Details |
|---|---|
| Model | WMX-ASD 120 5 (120-Output Voltage, 5-Output Current) |
| Input Voltage |
1 Phase: AC220V / AC230V / AC240V±10%, 50Hz/60Hz 1 Phase: AC110V±10%, 50Hz/60Hz (Optional) |
|
1) 3 Phase: AC208V / AC220V±10%, 50Hz/60Hz (Customization) 2) 3 Phase: AC380V / AC400V±10%, 50Hz/60Hz (Customization) |
|
| Output Voltage/Current Customize range | 0~120V, 0% to 100% adjustable, 0.5~5A, 10% to 100% adjustable. |
| Output Power | 600W |
| Output mode | Constant voltage & Constant Current |
| Load Regulation | ≤0.5%+30mV |
| Ripple | ≤0.5% + 10mVrms |
| Power supply stability | ≤0.3%+10mV |
| Voltage | Current Display Accuracy | Precision of 4 digit table : ±1%+1 word (10%-100% rating) |
| Voltage | Current value display Format | Display format: 0.000 ~ 9999V; 0.00 ~ 99.99V; 0.0 ~ 999.9A; |
| Output Voltage Overshoot | Build in O.V.P Protection with a rate of + 5% |
| Operation Temperature | Humidity | Operation Temperature : (0~40)°C; Operation Humidity : 10% ~ 85% RH |
| Storage Temperature | Humidity | Storage Temperature : (-20~70)°C; Storage Humidity : 10% ~ 90% RH |
| Over-Temperature Protection | (75~85) °C. |
| Heat Dissipation Mode/ Cooling mode | Forced air cooling |
| Efficiency | ≥86% |
| Start-up Output voltage setting time | ≤3S |
| Protections | Lower voltage, over voltage, over current, short circuit, overheating. |
| Insulation Strength |
Input output: AC1500V, 10mA, 1 minutes; Input - machine shell: AC1500V, 10mA, 1 minutes; Output - shell: AC1500V, 10mA, 1 minutes |
| Insulation Resistance | Input-Output ≥20MΩ; Input-Output ≥20MΩ; Input-Output ≥20MΩ. |
| MTTF | ≥50000h |
| Remote Control Function (Customization) | 0-5Vdc /0-10Vdc analog signal control output voltage & current |
| 0-5Vdc /0-10Vdc analog signal to read-back output voltage & current | |
| 0-5Vdc /0-10Vdc analog switch signal to control output ON/OFF | |
| 4-20mA analog signal control output voltage & current | |
| RS232/RS485 Communication port control by computer | |
| Dimension /Net Weight | 350*160*150mm, NW: 7.5kg |
