Wemax Power
1 / 5
| Model | WMX-ASD 80 12.5 |
| Model Name | 80v 12.5a dc power supply |
| Input Voltage |
1 Phase AC220V±10%, 50Hz/60Hz 1 Phase AC110V±10%, 50Hz/60Hz (Optional) |
| Output Voltage | 0V~80V adjustable output |
| Output Current | 1.25A~12.5A adjustable output |
| Output Power | 1000W |
| Load Regulation | ≤0.5% + 30mV |
| Ripple | ≤0.5% + 10mVrms |
| Power Supply Stability | ≤0.3% + 10mV |
| Voltage / Current Display Accuracy | Precision of 4 digit table: ±1% + 1 word (10%-100% rating) |
| Display Format | Display format: 0.000 ~ 9.999V; 0.00 ~ 99.99V; 0.0 ~ 999.9A |
| Output Voltage Overshoot | Build in O.V.P Protection with a rate of + 5% |
| Operation Temp. / Humidity | Operation Temperature: (0~40)°C; Operation Humidity: 10% ~ 85% RH |
| Storage Temp. / Humidity | Storage Temperature: (-20~70)°C; Storage Humidity: 10% ~ 90% RH |
| Over-Temperature Protection | (75~85)°C |
| Cooling Mode | Forced air cooling |
| Efficiency | ≥86% |
| Start-up Output Voltage Setting Time | ≤3S |
| Protections | Lower voltage, over voltage, over current, short circuit, overheating Protections. |
| Insulation Strength |
Input - Output: AC1500V, 10mA, 1 minute; Input - Machine Shell: AC1500V, 10mA, 1 minute; Output - Shell: AC1500V, 10mA, 1 minute |
| Insulation Resistance | Input - Output ≥20MΩ; Input - Shell ≥20MΩ; Output - Shell ≥20MΩ |
| MTTF | ≥50000h |
💡 Note Options:
| Input Voltage | 3 Phase: AC208V / AC220V±10%, 50/60Hz |
| Remote Control Functions | 4-20mA / 0-5Vdc / 0-10Vdc analog signal control output voltage & current & ON/OFF |
| 0-5Vdc / 0-10Vdc analog signal to read-back output voltage & current | |
| RS232/RS485 Communication port control by computer | |
| Custom-made functions are available upon request. | |
