Buck boost Isolation Dc Regulator 3a 72w Voltage Step up Down 12v 24vdc to 24v Isolated Converter

1 / 5

Buck boost Isolation Dc Regulator 3a 72w Voltage Step up Down 12v 24vdc to 24v Isolated Converter

Send Inquiry

Product Description

Buck Boost Isolation DC Regulator

3A 72W Voltage Step Up Down 12V 24VDC to 24V Isolated Converter

12v/24v to 24v isolated converter

Isolate dc dc converter, Safe and reliable

Light weight, small size, easy install

Supports wide range voltage input

Imported industrial grade power chips

Synchronous rectification technology with high conversion efficiency

Sufficient power

Isolation transformer, isolation voltage: 1500VDC

Isolate power supply, isolate input and output from each other, prevent burn out expensive load equipment

ABS tough shell, flame retardant and explosion-proof, corrosion resistant, antioxidant, good insulation, fast heat dissipation

Waterproof (IP67 waterproof grade), shockproof, moisture-proof, dustproof

Adapt to ambient temperature -20~85 ° C

Multiple protection: Over current, over voltage, over temperature, short circuit protection, strong anti-interference

Widely used: intelligent robots, communication base stations, industrial control, power supply systems, onboard equipment, etc.

Series No.	WMX-D9-36D24
Model	WMX-DSD9-36S2403
Product Name	12v/24v to 24v 3a isolated Converter
Input rated voltage	12/24Vdc
Input voltage range	9-36Vdc
Conversion Efficiency	96%
Output voltage	24Vdc
Output current	3Amps
Output rated power	72Watts
Voltage regulation	< 1%
Load regulation	< 2%
Ripple (full load test)	< 150mV
No-load current	< 20mA
Working Temperature	-40°c ~ +80°c
Waterproof rating	IP 67
Protections	Over-load, Over-current, Over-temperature, Over-voltage
Machine size	747432mm
N. Weight	290g
Type	Input & output Isolation
Packing	White standard box

Product Overviews

Buck boost Isolation Dc Regulator Overview 1

Buck boost Isolation Dc Regulator Overview 2

Buck boost Isolation Dc Regulator Overview 3

Buck boost Isolation Dc Regulator Overview 4

Buck boost Isolation Dc Regulator Overview 5

Buck boost Isolation Dc Regulator Overview 6

Buck boost Isolation Dc Regulator Overview 7

Buck boost Isolation Dc Regulator Overview 8

Buck boost Isolation Dc Regulator Overview 9

Buck boost Isolation Dc Regulator Overview 10

Buck boost Isolation Dc Regulator Specifications 1

Buck boost Isolation Dc Regulator Specifications 2

Buck boost Isolation Dc Regulator Banner

Buck boost Isolation Dc Regulator Features Design

Buck boost Isolation Dc Regulator Application

Buck boost Isolation Dc Regulator Information Footer

Frequently Asked Questions

Q1. How do we work?

Since 2009, our factory has provided various power solutions for different projects worldwide, including DC to DC, AC to DC, DC to AC, and AC to AC power supplies. We are committed to providing high-quality, high-performance, and cost-effective options to meet the power conversion needs of our customers.

Q2. What kind of products can you buy from us?

DC-DC Converter, DC-DC Charger, Voltage regulator, Adjustable Power Supply, Power Inverter, Battery Charger, AC DC Converter, Switching Power Supply.

Q3. How do you ensure your product and service quality?

All our processes strictly adhere to ISO-9001 procedures. And we have 12 months quality warranty against delivery date. If the product does not work properly as described, and the problem is proven to be caused by our factory, we will provide exchange services for the same specific item. Also, our professional support staff will always be there for you if anything is needed.

Q4. Can you provide custom services based on specific requirements?

Yes, we can provide bespoke service to customers with specific requirements. You can send the detailed requirements, and we will check if we can develop them. We develop new models every month, and some of them may not yet be updated on our website. Or you can send us samples and we can develop the new models especially for you.

Q5. Can I buy 1 or 2 pieces of samples for testing before placing a bulk order?

Yes, we are pleased to send you samples to test the quality and performance. We are confident that once you get it in your hand, you will be very satisfied. Moreover, with our excellent service and competitive price, we believe that we will be your good choice for power supply solutions.

Q6. What is your Minimum Order Quantity?

Different products have different MOQ. Generally speaking, our MOQ is 1pc. Please don't hesitate to check with us for specific items.
